Automatic Transfer Switches
|
by Purrfect Campers LLC
|
Automatic Transfer Switches
|
 |
The "Purrfect" solution for adding an
inverter and/or a generator to your RV
|
3-Way Switches allow the connection of Shore Power, Generator, and an Inverter
2-Way Switches allow the connection of 2 power sources |
|
Note: If you already have a generator with a transfer switch, you can add a 2-way transfer switch with a cutout relay. (See below) |
|
|
Charging Cutout Relay Option
|
 |
- Prevents the inverter from trying to recharge your batteries
- Eliminates the hassle of remembering to turn breakers on and off
- Keeps your system operating more efficiently without your interaction
|
|
|
|
|
Answer a couple of questions to find the switch that is right for you.
|
|
|
|
Features and Specs |
|
|
|
| |
Price: 270.00
In stock: 0
|
Price: 399.00
In stock: 0
|
Price: 299.00
In stock: 0
|
| Model: |
A-01-2WXFER240C |
A-01-3WXFER240C |
A-01-2WXFER240G |
| Type: |
2-Way |
3-Way |
2-Way |
| Inputs: |
Shore/Inverter |
Shore/Genset/Inverter |
Shore/Genset |
| Charging Cutout Relay: |
Yes |
Yes |
No |
| Voltage: |
240/120 VAC |
| Amps: |
50A (30A Inverter) |
50A |
| Max Charger Amps: |
20A |
-- |
| Switch Delay: |
No Delay |
Generator Delay
Adjustable in 1 sec steps |
| Min Operating Voltage: |
100 to 110V |
| Recommended Wire: |
Stranded (SJTW or 105℃ marine) |
| Shore Wire Rating: |
6 AWG |
| Generator Wire Rating: |
-- |
6 AWG |
| Inverter Wire Rating: |
10 AWG |
-- |
| Output Wire Rating: |
6 AWG |
| C/O Relay Wire Rating: |
14 to 12 AWG |
-- |
| Width: |
8" |
15" |
10" |
| Length: |
10" |
15" |
10" |
| Height: |
4" |
6" |
4" |
| Enclosure: |
Steel NEMA 1 |
| |
|
|
|
|
 |
| Made in the USA with parts sourced locally and internationally |
